| Business Type | Exporter, Supplier, Retailer, Trader |
| Bore x Stroke | 103 Mm × 110 Mm. |
| Displacement | 3.7 Litres (for The 4-cylinder Version) |
| Powder Output | 91 Kw (≈ 260 Hp) At 3,500 Rpm |
| Click to view more | |
Product Details
The Volvo Penta D4-260 is an in-line 4-cylinder, 3.7-liter diesel engine featuring common-rail fuel injection, double overhead camshafts, and a turbocharger. This advanced marine engine offers excellent operating economy, high reliability, and long-term durability, making it ideal for both leisure and commercial vessels.
Key Features & Advantages High Performance
The D4-260 delivers immediate response and superior performance, combined with low noise and vibration levels. The inclusion of a balance shaft and optimized engine suspension ensures smooth operation and exceptional onboard comfort.
Compact and Robust
Designed for maximum efficiency and ease of installation, the D4-260 is extremely compact for its displacement.
A rigid cast-iron cylinder block and head, integrated balance shaft, and precisely controlled fuel injection system contribute to durability, stability, and quiet operation — ensuring excellent onboard comfort.
Unique Marine Torque
Volvo Penta diesel engines are known for their unique marine torque characteristics, offering:
-
Increased load-carrying capability
-
Rapid acceleration
-
Consistent cruising speed — regardless of sea conditions or vessel load
This ensures powerful maneuverability and efficient cruising in all marine environments.
Low Fuel Consumption
A high-tech fuel injection system, managed by an advanced engine control unit (ECU), continuously monitors and adjusts key parameters. This intelligent control results in low fuel consumption, improved efficiency, and reduced emissions.
Electronic Control Systems
Volvo Penta provides two type-approved electronic control systems for seamless integration and operational precision:
-
Electronic Vessel Control (EVC): Integrates engines, electronics, and a variety of optional features for enhanced vessel management.
-
Marine Commercial Control System (MCCS): An open system that can be easily incorporated into existing ship control architectures.
Volvo Penta propulsion systems are engineered for long-lasting performance and ease of maintenance. A comprehensive range of high-quality oils, lubricants, and coolants helps maintain top efficiency and reliability. Optional accessories such as a fuel pre-filter further extend engine life and minimize downtime.
Technical Features
-
Electronically controlled common-rail fuel system
-
Compact dimensions
-
Electronic controls as standard
-
Easily accessible service points
-
Solid and robust engine design
-
Integrated balance shaft
-
Heavy-duty engine cover
-
PTO (Power Take-Off) capability
-
Instrumentation with full Electronic Vessel Control functionality
